Gloss Meter PICOGLOSS 503

Gloss Meter Picogloss 503

Enquire Now Download E-Brochure

Manufacturing Partner:

It is very important to achieve a consistent surface quality during the production and processing of surface-treated materials (such as papers, plastics, metal or wood surfaces). A uniform and defined surface quality must be ensured in almost all industrial segments. Differences in glossiness can result from manufacturing defects, supplier changes and material fluctuations. Often, these lead to complaints in quality control or even rejection of the material. Especially in recent years due to increasing demands of customers, it is particularly important to be able to make a flawless, objective assessment of the gloss.

Category:
Share:
Share :

Product Specifications

Instrument Model Test Principle Measuring angles
Picogloss 503 A glossmeter is an instrument that is used to measure the specular reflection (gloss) of a surface. The Gloss of a surrface is evaluated by applying a beam of light at a fixed intensity and angle onto a surface and measuring the amount of reflected light at an equal but opposite angle. 20°, 60° and 85° gloss unit

Features

  • The PICOGLOSS is a handheld instrument which measures three-angle gloss with measuring geometries of 20°, 60° and 85°.
  • DIN, ISO, ASTM, BS and JIS of all three gloss ranges High, medium and low gloss unit
  • The PICOGLOSS 503 is operated by using a scroll wheel present in the instrument and it has user-friendly navigation on the color display.
  • The measuring procedure is started by actuating a key that is located at the side in an ergonomic manner.
